Flexfiller Midi
Compact and totally enclosed digital pressurisation units with electronic pressure transducer and user-friendly microprocessor for use on sealed system in order to provide a minimum system pressure requirement.
The Flexfiller Midi is a wall mounted, flow rate (up to 12 l/min) top-up pressurisation unit with 4 litre internal break tank. Ideal for Industrial, commercial or large domestic applications. Available in single or twin pump configuration.
Application:
- Commercial, Industrial and Residential
System Volume (Guide): < 50,000 litres.
Enquiry about Flexfiller Midi
Enter the security code shown above
Description
Product Features:
- For system volumes up to 50,000 liters.
- Fluid Protection Category 5 (AB Weir Overflow).
- System fill mode.
- Onscreen Service Reminder – 12 Months.
- Electric pump, 230V 50Hz 1ph.
- Colour: White (RAL 9003).MODBUS RTU Communication Protocol.
- Password protected.
- Sequential programming menu.
- Pressure setting in 0.1 bar increments.
- Pump pulse option.
- Flood Protection (Pump Runtime Limiter, Excessive Start Alarm).
- Event logging:
- Alarm activations, Pump Run counter (activations per pump), Cumulative run timer (hours per pump), Electrical interruption.
- Volt free contacts: Common Alarm (N/C), High-Pressure Alarm (N/O), Low-Pressure Alarm (N/O), Sensor Health (N/O), Pump 1 Health (N/O), Pump 2 Health (N/O).
Operating Conditions:
- The system temperature range at the point of connection: 5 ºC / 85 ºC.
- Ambient temperature range: 5 ºC / 40 ºC.
- Pressure rating: PN 10.
- Relative humidity 95% non-condensing.Noise Rating Data: < 75 dBA.
Certifications and Standards Applied:
- PED 2014/68/EU Sound Engineering Practice.
- IEE – Electrical Safety Guidance.
- EMC 2004/108/EC.BS 7074 Parts 1 to 3.
- Machinery Directive 2006/42/EC.Electronic Components have been tested and comply with the EMC Directives.
- EN 61000-6-1: Generic Standards – Immunity standard for industrial environments.
- EN 61000-6-2: Generic Standards – Immunity standard for industrial environments.
- EN 61000-6-3: Generic Standards – Emission standard for residential, commercial, and light industrial environment.
- CE marked components, where applicable.
- WRAS approved the float valve to BS1212.
- IP54 (BS EN60529) rated controller.
The material of Construction:
- Cabinet: Mild steel CR4 Powder Coated.
- Float: WRAS approved.
- Break Tank: Polypropylene.
- Connection: Brass / Polypropylene.
- Pipework: Braided Flexhose / EPDM / Copper.
- Finish: Powder coated.
- Valves: Brass / PTFE.
